SECURVIEW 4MP HDCVI CAMERA 30x ZOOM PTZ DOME
FAST PRESET PTZ SPEED UP TO 400°/s PANNING

4.0MP@25fps, 4.5~135mm (60~2.2°), 100m IR, true WDR, HDCVI/SD switch video out, audio & alarm, 360° endless pan, -15°~90° tilt, IP67, 24VAC , power supply and right angle bracket included.

Every moment captured with the Securview HDCVI PTZ series. This professional PTZ delivers the very best in automated long-range PTZ surveillance with rapid preset camera movement, endless 360° panning and lossless optical zoom.

Stream up to 4.0MP (2592 x 1520) at 25fps

Motorised varifocal lens with auto iris

Up to 30x lossless optical zoom lens

Up to 700m video transmission over coaxial cable

Smart infrared illumination, up to 100m range

Endless 360° pan, with fast 400°/s pan, 300°/s tilt speed

2/1 alarm input/output and 1 channel audio input

True WDR (120dB) & 3D digital noise reduction

HDCVI / composite switchable via DIP switches

Mounting options:

Right angle VSBKTA300S (Wall Mount Bracket (Included))
Ceiling Mount: MB1028 + MB1042
Junction Box: MB1038 + VSBKTA300S (Wall Mount Bracket (Included)) + MB1042 (Wall Mount Adaptor(included))
Power Box Mount: MB1037 + VSBKTA300S (Wall Mount Bracket (Included)) + MB1042 (Wall Mount Adaptor(included))
Pole Mount: MB1025 + VSBKTA300S (Wall Mount Bracket (Included)) + MB1042 (Wall Mount Adaptor(included))
Parapet Mount: MB1063 + MB1042 (Wall Mount Adaptor(included))

Specifications:

Type	HDCVI varifocal PTZ camera
Size	309x186mmØ
Power	24Vdc
Colour	White/Black
TVL	4.0MP
FOV	60° (wide) ~ 2.2° (tele) 30x optical zoom
Lens	4.5 ~ 135mm Motorised
LUX	0.05
CCD	4.0M CMOS 1/3"
Resolution	4.0M
Outdoor	IP66
IR	100M
Pan/Tilt/Zoom	Pan: 0°~360° endless / Tilt: -15°~90° / Auto-flip 180°
Style	PTZ
Feature	Zoom
Protocol	HD-CVI
